Fermax MDS DIRECT User Manual

Pag. 10
Technical Book
MDS-ADS
MDS-ADS
EXAMPLE 3.
Facility of 8 blocks with 115 apartments each, (each block with an ADS).
Observations:
- We want the apartment numbers in each block to start from number 1.
- We want to program the house terminals (monitors/telephones) from the General Entrance Panel. See
"Programming house terminals from GENERAL ENTRANCE".
- Owing to the facility features all blocks are
TYPE B --> B i i i / B f f f, (Large Blocks, 199 apartments per
block and up to 9 blocks).
Programming:
1. Follow the steps in "Enter Programming mode".
2. Follow the steps defined in "ADS Decoder Programming (depending on Type)", (there is one decoder per
block).
Enter
STEPS
1
Programming mode
Enter
STEPS
1
Programming mode
Enter
STEPS
1
Programming mode
Audio-4:
Telephone 1: 1 0 0 1
Audio-4:
Telephone 2: 1 1 1 5
Audio-4:
Telephone 3: F F F F
Audio-4:
Telephone 4: F F F F
Block 1
(115 Apartments)
Audio-4:
Telephone 1: 2 0 0 1
Audio-4:
Telephone 2: 2 1 1 5
Audio-4:
Telephone 3: F F F F
Audio-4:
Telephone 4: F F F F
Block 2
(115 Apartments)
Audio-4:
Telephone 1: 8 0 0 1
Audio-4:
Telephone 2: 8 1 1 5
Audio-4:
Telephone 3: F F F F
Audio-4:
Telephone 4: F F F F
Block 8
(115 Apartments)
...................................
ADS Decoder
2
Programming
Initial address
2: Block nº.
001: Initial house nº.
Final address
2: Block nº.
115: Final house nº.
FFFF -> Monitors/
telephones will be
programmed from the
G. E. panel
Blocks 3, 4, 5, 6, 7
(will be programmed in the same way)
This output NOT to be
PROGRAMMED. Leave
in FFFF.
