Technical Book
MDS-ADS
MDS-ADS
MDS-ADS SYSTEM PROGRAMMING
EXAMPLE 2.
Facility of 230 Chalets/Villas with 1 panel with 1 Line in each one.
Observations:
- We want the house numbers to start from number 1.
- We want to program the house terminals (monitors/telephones) from the 1 Line ADS house panel. See
"Programming house terminals from INTERIOR BLOCK."
- Due to the features of the facility we would be in
TYPE A --> i i i i / f f f f, (Chalets/Villas, up to 9999).
Programming:
1. Follow the "Enter Programming mode" steps.
2. Follow the steps defined in "ADS Decoder Programming (depending on Type)", (there is one decoder per
house).
Enter
STEPS
1
Programming mode
Enter
STEPS
1
Programming mode
Enter
STEPS
1
Programming mode
Audio-4:
Telephone 1: 0 0 0 1
Audio-4:
Telephone 2: 0 0 0 1
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Chalet 1
(1 House)
Audio-4:
Telephone 1: 0 0 0 2
Audio-4:
Telephone 2: 0 0 0 2
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Chalet 2
(1 House)
Audio-4:
Telephone 1: 0 2 3 0
Audio-4:
Telephone 2: 0 2 3 0
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Chalet 230
(1 House)
...................................
ADS Decoder
2
Programming
Houses from 3 to 229
(will be programmed in the same way)
Initial address 2
Final address: 2
0000 -> The monitor/
telephone will be
programmed from the
ADS panel.
This output is NOT to be
PROGRAMMED. Leave
in FFFF.
