Fermax MEMORY 4+N LOFT COMPACT - Installation and Connections

Pag 20
INSTALLATION AND WIRING
DisassemblyAssembly
1
2
Wiring
2 OUTPUTS VIDEO DISTRIBUTOR
DISTRIBUIDOR VIDEO 2 SALIDAS
V
5
V
1
M
+18
75
M
R1
34
+
V
2
REF.2448
6
VM M
(-)
R
1
+
-
2
3
6
4
CT
Ct
+
M
V
V
F2
4
3
1
-
F1
2
6
TA
COAX
1.60m
5.25 feet
1
3
4
2
90º
NOTES:
- Only a maximum of 100 monitors can be installed on a 4+N system.
- To connect an additional monitor in the same residence a call multiplier must be
added Ref. 2340.
1,2,3,6: common audio.
4: call Wire.
+, -: power supply (18 Vdc).
V: live (coaxial - video)
M: shield (coaxial - video)
Ct: camera activation (10 Vdc)
T, -: Call Button residence.
A, +: Call Extension
