Troubleshooting, Adjustment & Service
PARKING BRAKE ADJUSTMENT
1. Park the machine on a flat, level surface.
Disengage the PTO, stop the engine, and engage
the parking brake.
2. Chock the drive tires and then release the parking
brake handle
3. Locate the two parking brake springs (A, Figure
31). One is located on the left rear side of the
engine deck by the left drive wheel and the other
is located on the rear right side of the engine deck
by the right drive wheel.
4. Loosen the set collar (B) and then tighten it snugly
against the white brake spring. Repeat process for
other side.
5. Re-engage the parking brake handle and unchock
the wheels.
If this does not correct the braking problem, see
you Ferris dealer.
A
B
Figure 31. Parking Brake Adjustment
A. Parking Brake Spring
B. Set Collar
