SETUP OF THE SYSTEM
Parameters list
N° Code Meaning Setting range Default
Adjust
precision
UM
1 - Working Mode Auto, Cool, Heat, DHW Heat/ DHW / /
2 - Room setting temp
cooling:17~30 24 1 ºC
heating:17~30 24 1 ºC
auto:17~30 24 1 ºC
3 - Water outlet setting temp
Cooling 1: 5~25 7 1 ºC
Cooling 2: 18~30 18 1 ºC
Heating 1: 25~55 35 1 ºC
Heating 2: 35~60 45 1 ºC
4 - Domestic hot water tank DHW setting temp 40~60 50 1 ºC
5 - Screen lock time 60~300 120 10 S
6 - Disinfect time 0:00~23:00 23.00 10 MIN
7
Pump running time
(DHW time)
DHW water pump running time 5-120 5 1 MIN
8 - Time 0:00~24:00 1
HOUR/
MIN
9 - Date 01-01-2000~31-12-2099 01/01/2016 1 /
10 - Silent level 1~2 1 1 /
11 T1S Water outlet setting temp of the fi rst heating fl oor 25~35 25 1 ºC
12 t_fi rstFH Running time of the fi rst time heating fl oor 48~96 72 12 HOUR
13 T4DHWMAX Max. operation ambient of DHW mode 35~43 43 1 ºC
14 T4DHWMIN Min. operation ambient of DHW mode -20~5 -10 1 ºC
15 dT1SC Temp difference to start of water outlet temp in cooling mode (fl ow sensor) 2~10 5 1 ºC
16 dTSC Temp difference to start of room temp in cooling mode (room sensor) 1~10 2 1 ºC
17 T4CMAX Max. operation ambient temp in cooling mode 35~46 43 1 ºC
18 T4CMIN Min. operation ambient temp in cooling mode -5~25 10 1 ºC
19 dT1SH Temp difference to start of water outlet temp in heating mode (fl ow sensor) 2~10 5 1 ºC
20 dTSH Temp difference to start of room temp in heating mode (room sensor) 1~10 2 1 ºC
21 T4HMAX Max. operation temp of heating mode 20~35 25 1 ºC
22 T4HMIN Min. operation temp of heating mode -20~5 -15 1 ºC
23 T4AUTOCMIN Min. operation temp of cooling in Auto mode 20-29 25 1 ºC
24 T4AUTOHMAX Max. operation temp of heating in Auto mode 10-17 17 1 ºC
25 T1S_H.A_H Water outlet setting temp in holiday mode 20~25 25 1 ºC
26 T5S_H.A_DHW Water tank setting temp in holiday mode 20~25 25 1 ºC
27 T5S_disinfect Setting temp of Disinfect mode 60~70 65 1 ºC
28 t_DI_HIGHTEMP. Keep time when reach setting temp in disinfect mode 5~60 15 5 MIN
29 t_DI_max Operation time of disinfect mode 90~300 210 5 MIN
30 t_DHWHP_MAX Max. running time of DHW mode 10~600 120 5 MIN
31 t_DHWHP_RESTRICT Max. running time of heat pump mode 10~600 10 5 MIN
32 dT5_ON Temp difference to start of water temp in DHW mode 2~10 5 1 ºC
33 dT1S5 Temp difference to start of water outlet temp in DHW mode 5~20 10 1 ºC
34 t_TBH_DELAY Activation delay time of DHW tank electrical heater 0~240 90 5 MIN
35 dT5_TBH_ OFF DHW tank temperature difference for DHW resistance deactivation 0~10 5 1 ºC
36 T4_TBH_ON Ambient temp of TBH start -5~20 5 1 ºC
37 T4_IBH_ON Ambient temp of IBH start -15~10 -5 1 ºC
38 dT1_IBH_ON Temp difference to start IBH 2~10 5 1 ºC
39 t_IBH_DELAY IBH delay Start Time 15~120 30 5 MIN
40 t_IBH12_DELAY IBH1,2 delay Start time 5~30 5 5 MIN
41 T4_AHS_ON Ambient setting temp of AHS start -15~10 -5 1 ºC
42 dT1_AHS_ON Temp different of AHS start 2~10 2 1 ºC
43 dT1_AHS_OFF Temp different of AHS stop
-5~0
01ºC
44 t_AHS_DELAY AHS Delay start time 5~120 30 5 MIN
45 t_INTERVAL_C Compressor start interval time in cooling mode 5~30 5 1 MIN
46 t_INTERVAL_H Compressor start interval time in heating mode 5~60 5 1 MIN
47 t_INTERVAL_DHW Compressor start interval time in DHW mode 5~30 5 1 MIN
48 t_DRYUP Running time of rise to T_DRYPEAK 4~15 8 1 DAY
49 t_HIGHPEAK Keep time of reach the T_DRYPEAK 3~7 5 1 DAY
50 t_DRYD Running time of reduce the water outlet temp 4~15 5 1 DAY
51 T_DRYPEAK Water outlet Setting temp of fl oor drying mode 30~55 45 1 ºC
To Next Page
