The appearance of the wire control device
Enter the
menu struc-
ture from the
page
Navigate the
cursor on the
display/naviga-
te in the menu
structure/
adjust the
settings
Come back to
the up level
Go to the next step when programming a sche-
dule in the menu structure / confirm a selection/
enter a submenu in the menu structure
Status icons
Long press for unlocking /
locking the controller
unlock /lock some function such
as ''TANK'' temp.
adjusting''
Turn on or off the space operation
mode or DHW mode turn on or off
the function in the menu structure
Lock icon
Timer icon
Prevent freezing icon
The AHS
(additional heating source such as
gas boiler) is activated
A malfunction occured
Silent mode is activated
The disinfect function is activated
Holiday away/home is activated
Backup heater is activated
The compressor is activated
Desired temp.
DHW mode
will not change will decrease will increase
TANK
55
C
C
27
SET
SET
08 : 30
C
ON
ON
DHWMAIN
21: 55 08 - 08 - 2015 SAT.
DHW Tank temp.
Heat mode
Cool mode
Auto mode
Mode
is operating
A
At the next scheduled action, the desired temperature:
Shutoff
ECO mode
is activated
Tank heater
is activated
Defrost mode
is activated
The solar
energy
is activated
Weekly
schedule
7
Comfort mode
is activated
