This menu is for installer or service engineer to see all the
operation parameters.
■ At home page, go to ''MENU'' > ''OPERATION PARAMETER''.
■ Press ''OK''. There are five pages for the operating parame-
ter as following. Use ''▼'', ''▲'' to scroll.
About For Serviceman
FOR SERVICEMAN is used for installater and service en-
gineer.
■ Setting the composition of equipment.
■ Setting the parameters.
Go to ''MENU'' > ''FOR SERVICEMAN''. Press ''OK''.
How To Exit For SERVICEMAN
If you have set all the parameter.
Press ''BACK'', the following page will be appear:
■ The FOR SERVICEMAN is used for installer or service en-
gineer. It is NOT instended the home owener alters setting
with this menu.
■ It is for this reason password protection is requierd to pre-
vent unanthorised access to the service settings.
Operation Parameter
FOR SERVICEMAN
OPERATION PARAMETER
P2 COMP. PRESSURE2 --kPa
POWER CONSUMPTION OKWH
OPERATION PARAMETER
T1 WATER FLOW TEMP. 25°C
30°C
T2 PLATE F-OUT TEMP.
45°C
T2B PLATE F-IN TEMP.
-7°C
T3 OUTDOOR EXCHANGE TEMP.
-7°C
T4 OUTDOOR AIR TEMP.
-7°C
T5 OUTDOOR AIR TEMP.
SCROLL 3/5
OPERATION PARAMETER
COMP.RUN TIME4 1000HOUR
EXPANSION VALUE 240P
600 R/MINFAN SPEED
0 ABACKUP HEATER1 CURRENT
0 ABACKUP HEATER2 CURRENT
T1 LEAVING WATER TEMP.1 25°C
SCROLL 2/5
OPERATION PARAMETER
Ta Room temp
25°C
P1 COMP. PRESSURE1 200kPa
SCROLL 4/5
25°C
Tw-0 PLATE W-OUTLET TEMP.
25°C
Tw-I PLATE W-INLET TEMP.
25°C
Th COMP.SUCTION TEMP.
25°C
Th COMP.SUCTION TEMP.
OPERATE MODE COOL
COMPRESSOR CURRENT 12A
24HzCOMPRESSOR FREQUNCY
54MINCOMP.RUN TIME1
65MINCOMP.RUN TIME2
10MIN
COMP.RUN TIME3
SCROLL 1/5
if some parameter is not be activated (or available), the para-
meter will show "--" .
INFORMATION
FOR SERVICEMAN
Please input the password:
ADJUST SCROLLENTER
OK
0 0 0
FOR SERVICEMAN
Do you want to exit the for
serviceman?
SCROLLCONFIRM
OK
NO YES
CONTROL SYSTEM
When you exit from the menu FOR SERVICEMAN, the
unit will be turned off.
INFORMAZIONE
To Next Page
