Pipe parts
02
The pipe parts are located in a small individual package inside the box.
Bracket installation
03
Please insert the pipe into the plastic
part of the same number and secure it.
The bracket need to be installed in place
and tightly twisted the screw to avoid
dropping.
Insert the bracket and drum tray into
the corresponding positi ons, and then
tighten the screws.
Note: (tom, snare) the functions are
different, you need to refer to the
accessories lo go for correct
installation!
INSTALLATION GUIDE
4
A
B
A
E
B
A
D
D
C
A
D
E
C
D
