Valve terminals type 32 MPA
Peripherals overview
Pneumatic components of the valve terminal – Multi-pin plug, AS-interface
Designation Brief description  Page/Internet
1 Electronics module – 73
2 Solenoid valve Size 1 69
3 Cover cap for manual override Conversion from detenting/non-detenting to non- detenting or covered –
4 Blanking plate For unused valve position (vacant position), size 1 74
5 Mounting Optional for valve terminal mounting (on supply plate) 71
6 Flat plate silencer – –
7 Exhaust plate For ducted exhaust ai r 74
8 Regulator plate Size 2 70
9 Solenoid valve Size 2 69
aJ Blanking plate For unused val ve position (vacant position), size 2 74
aA H-rail mounting – 71
aB Right- hand end plate – 72
aC Separating seal For manifold block 74
aD Fittings For working lines 76
aE Inscription label – 76
aF Manifold block Size 2 71
aG Fittings For pneumatic supply plate 76
aH Supply plate – 74
aI Electrical manifold module For multi-pin plug connection, for AS-interface 73
bJ Manifold block Size 1 71
