Valve terminals type 32 MPA
Peripherals overview
Pneumatic components of the valve terminal – CPI connection, fieldbus
The manifold blocks are either
prepared for:
• 2 or 4 single solenoid valves
• 2 or 4 double solenoid valves
depending on the size.
• Double solenoid valve positions
can be equipped with any valve or a
blanking plate.
• Single solenoid valve positions can
onlybeequippedwithsingle
solenoid valves.
