Valve terminals type 32 MPA
Peripherals overview
Pneumatic components of the valve terminal – CPI connection, fieldbus
Designation Brief description Page/Internet
1 Electronics module – 73
2 Solenoid valve Size 1 69
3 Cover cap for manual override Conversion from detenting/non-detenting to non- detenting or covered –
4 Blanking plate For unused valve position (vacant position), size 1 74
5 Electrical manifold module For fieldbus connection, for proportional pressure regulator 73
6 Mounting Optional for valve terminal mounting (on supply plate) 71
7 Flat plate silencer – –
8 Exhaust plate For ducted exhaust ai r 74
9 Mounting Optional for val ve terminal mounting
(on the manifold block of the proportional pressure regulator)
71
aJ Electrical module For proportional pressure regulator 73
aA Proportional pressure regulator – 64
aB Regulator plate Size 2 70
aC Solenoid valve Size 2 69
aD Blanking plate For unused val ve position (vacant position), size 2 74
aE H-rail mounting – 71
aF Right- hand end plate – 72
aG Separating seal For manifold block 74
aH Fittings For working lines 76
aI Manifold block Size 2 71
bJ Manifold block For proportional pressure regulator 71
bA Pressure sensor – 74
bB Fittings For pneumatic supply plate 76
bC Supply plate – 74
bD Electrical supply plate For auxiliary voltage supply for large valve terminals 73
bE Inscription label – 76
