Festo CP-FB06-E - Pin Assignment

Festo CP-FB6-E 0112d English16
3 Pin assignment
0
1
3
2
SAVE
POWER
24 VDC
POWER V
ERROR V
RD
BA
RC
12
34
1 24 V operating voltage (electronics and inputs)
2 24 V load voltage (va lves and outputs)
3 0V
4 Earth connection
3.1 Meaning of the LED displays
Refer to manual “ CP fieldbus node 6 ”.
