Festo CP-FB06-E - Page 22

Festo CP-FB6-E 0112d English22
Type CP FB6-E
Pin 1
Operating voltage connection for
electronics (eletronics/inputs)
–Ratedvalue
–Tolerance
– Current consumption of the
CP-FB6-E
– Current consumption of the complete
CP system
24 V DC (protected against
incorrect polarity)
20.4...26.4 V
Max. 250 mA
See manual “CP system”,
current consumption table
Pin 2
Load voltage connection
(outputs/valves)
–Ratedvalue
–Tolerance
– Current consumption
24 V DC ( protected against
incorrect polarity)
20.4...26.4 V
Sum of all switch ed-on CP
solenoid v alves; see manual
“CP pneumatics”
Residual r ipple 4Vpp(withintolerance)
Detailed information on the CP FB6-E can b e found in the
manual P.BE-CP-FB6-E-.. .
