5. Analogue input module CPX-4AE-T
5-30
Festo P.BE-CPX-AX-EN en 1107f
5.5.2 LED display
LEDs are situated under the transparent cover of the module
for diagnosing the input modules.
1 Channel error LEDs
(red)
2 Module error LED
(red)
4
AE-T
1
2
Fig. 5/6: LE D displays of the temperature module CPX-4AE-T
