Behaviour of the display components of the module after error-free commissioning
[MD] [PL]
Illuminated green Illuminated green
Tab. 8 Behaviour of the LED displays of the module after error-free commissioning
Information on troubleshooting in the event of incorrect behaviour:
èInstruction manual for automation system CPX-AP
è 10 Diagnostics and fault clearance
9 Parameterisation
Various parameters are available for reading out information about the modules in an automation sys-
tem CPX-AP and adapting the modules to the application situation.
Write access to the parameters is typically performed by the higher-level controller using the device
descriptions specific to the host system.
ID Parameter Instance-
s
Data
type
Access
1)
Arraysize
246 Fieldbus serial number 1 UINT32 ro
–
791 Product key 1 CHAR ro 12
960 Firmware version 1 CHAR ro 30
20000 Module code 1 UINT32 ro
–
20022 Configuration of voltage monitoring load
supply PL
– 0: load voltage monitoring inactive
– 1: load voltage monitoring active, with
suppression of diagnostics at switch-
off (factory setting)
– 2: load voltage monitoring active
1 UINT8 rw
–
20052 Behaviour in error state (communication
fault)
– 0: reset outputs (factory setting)
– 1: maintain status
1 UINT8 rw
–
20085 Measured value temperature AP-ASIC [°C] 1 INT16 ro
–
