Festo VPPM Series User Manual

VPPM−...−DE/EN
Festo VPPM−... 0810b English
41
8 Dismantling
Dismantling:
S Switch off the following sources of energy:
 operating voltage
 compressed air.
S Disconnect the relevant connections from the VPPM−...
S Remove the VPPM−... from the mounting surface/H−rail.
9 Accessories
Designation Type
 Plug socket with cable, straight
 Plug socket with cable, angled
 Y−cable (to connect the VPPM−... to analogue
inputs/outputs)
SIM−M12−8GD−...−PU
NEBU−M12W8−...−N−LE8
NEBV−M12G8−KD−...−M12G5
 H−rail mounting
 Bracket
 Sub−base
VAME−P1−T
VAME−P1−A
VABM−P1−SF−G18−...−P3
Fig.21

Festo VPPM Series Specifications

General

With accessories	Yes
Supply voltage	24 V DC
Electrical connection	M12x1
Operating medium	Inert gases
Mounting type	Manifold rail
Control characteristic	Proportional
Operating voltage	24 V DC
Protection class	IP65
Connection type	M12x1
Type	Proportional pressure regulator
Housing material	Plastic
