22
value, you can loosen the screw (22.1) and readjust
this value.
9.4 Replacing the tabletop insert
Never work with a worn table insert (20.1), replace
it with a new one.
– To replace the table insert, unscrew the six
screws (20.2).
9.5 Cleaning or replacing window for laser
(KS 120 EB only)
The window (21.2) for protecting the laser can
become dirty during operation. It can be removed
for cleaning or replacement.
– Release the screw (21.5) by approx. 2 rota-
tions.
– Press the window at the same time in the direc-
tions (21.3) and (21.4).
– Remove the window.
–
Clean the window or replace it with a new one.
– Fit the cleaned/new window. Both of the pegs
(21.1) on the window must snap into the recesses
of the upper hood as shown in Fig. 21.
– Tighten the screw (21.5).
10 Disposal
Do not throw the power tool in your household
waste! Dispose of the machine, accessories and
packaging at an environmentally-responsible
recycling centre! Observe the valid national regu-
lations.
EU only: In accordance with European Directive on
waste electrical and electronic equipment and im-
plementation in national law, used electric power
tools must be collected separately and handed in
for environmentally friendly recycling.
Information on REACh:
www.festool.com/reach
11 EU Declaration of Conformity
Circular cross-cut saw Serial no.
KS 120 EB 495773, 495774, 495775,
495776, 495777
KS 88 E 496868, 496869, 496871,
496872
Year of CE mark KS 120 EB 2007
KS 88 E 2009
We solely declare that this product conforms with
the following standards and normative docu-
ments: EN 61029-1, EN 61029-2-9, EN 55014-1,
EN 55014-2, EN 61000-3-2, EN 61000-3-3 in
accordance with the regulations in Directives
2004/108/EC, 2006/42/EC,
2011/65/EU
.
Festool Group GmbH & Co. KG
Wertstr. 20, D-73240 Wendlingen, Germany
Dr. Johannes Steimel
Head of Research, Development and Technical
Documentation
2014-05-14
