Festool PRECISIO Series User Manual

14
1 Symbols
Warning of general danger
Risk of electric shock
Wear ear protection.
Wear a dust mask!
Read the operating instructions/notes
2 Technical data
Cutting depth at 90°/45° 0 - 70 mm/ 0 - 48 mm
Inclination -2° - 47°
Max. cutting length 330 mm
Saw blade 225 x 30 x 2.5 mm
Idling speed
CS 70 EB, adjustable 2000 - 4200 rpm
CS 70 E 4200 rpm
Power consumption 2,200 W
(110 V: 1,500 W)
Table dimensions (L x W) 690 x 500 mm
Bench height with foldaway legs 900 mm
Bench height without
foldaway legs 375 mm
Weight with foldaway legs 34 kg
Protection category of motor (CS 70 EB only)
and IP5X switch according to EN 60529.
Degree of protection
/ II
The specifi ed illustrations are at the beginning of
this operating manual.
Bench-mounted circular saw and circular
trimming saw
CS 70 E, CS 70 EB
3 Machine features
[1-1] Foldaway legs
[1-2] On/off switch
[1-3] Cable holder
[1-4] Table insert
[1-5] Rotary knob for adjusting the fence
[1-6] Spacer wedge
[1-7] Stop lever
[1-8] Cutting depth adjuster
[1-9] End cap
[1-10] Groove
[1-11] Rotary knob for adjusting the protective
cover
[1-12] Knobs for adjusting the foldaway legs
4 Intended use
The PRECISIO is designed as a transportable
electric power tool for sawing wood, plastics,
panel materials made of wood and similar mate-
rials. Special aluminium cutting blades supplied
by Festool allow you to use these machines to
saw aluminium. Materials containing asbestos
must not be processed.
The user bears the responsibility for damage
and accidents caused by improper use.
5 Safety instructions
WARNING! Read all safety warnings and
all instructions. Failure to follow the warn-
ings and instructions may result in electric shock,
fi re and/or serious injury.
Save all warnings and instructions for future
reference.
- Never allow children to use the machine.
- Before using the machine, make yourself suf-
fi ciently familiar with the application, setting
and operation of the machine.
5.1 Machine-related safety instructions
- Only use tools that meet standard EN 847-1.
- Saw blades made of High Speed Steel (HSS
steel) must not be used.
- Only saw blades with the following specifi ca-
tions must be used: saw blade diameter of
225 mm; cutting width of 2.5 mm; toolhold-
er diameter of 30 mm; blade core thickness
of max. 2.2 mm; suitable for speeds of up to
4200rpm.
1 Symbols .................................................. 14
2 Technical data ......................................... 14
3 Machine features ..................................... 14
4 Intended use ............................................ 14
5 Safety instructions .................................. 14
6 Commissioning ....................................... 16
7 Machine settings ..................................... 16
8 Working with the machine ...................... 19
9 Service and maintenance ........................ 19
10 Disposal ................................................... 20
11 EU Declaration of Conformity ................. 20
