Fetco CBS-2032E - Page 18

18
13 57047 VALVE, DSV-11, 120 VAC (COIL, DIAPHRAGM, SPRING, & PLUNGER)
13 1 102193 ASSEMBLY, HOT WATER VALVE, 220VAC
EXPORT
220V ONLY
13 57071 VALVE, DSV-11, 220 VAC (COIL, DIAPHRAGM, SPRING, & PLUNGER)
EXPORT
220V ONLY
13 57073 VALVE REBUILD KIT, DSV11. (PLUNGER, SPRING, AND DIAPHRAGM)
14 2 83051 WASHER, #8 SCREW SIZE, FLAT
15 7 83026 WASHER, INTERNAL TOOTH LOCK, #8 SCREW SIZE,
16 17 84002 NUT, HEX, #8-32 MACHINE SCREW
17 1 108002 SWITCHING/CONTROL BOARD, 8 KEYS, D2P (CBS-2032e ONLY)
17 1 108038 SWITCHING/CONTROL BOARD, 8 KEYS, D2P (CBS-2032s ONLY)
18 4 15007 STANDOFF, MALE-FEMALE, THREADED HEX 4-40-1/2"
19 3 29007 NUT, #4-40 KNURLED THUMB
20 1 51042 BOARD, POWER SUPPLY-120VAC
20 1 51055 BOARD, POWER SUPPLY-220VAC
EXPORT
220V ONLY
21 4 29019 SPACER, .25" HEX x 1" LG., FEM, #4-40 THREAD
22 1 002065 WELDMENT, HOT WATER FAUCET
23 1 33007 LOCKNUT, 7/16 STRAIGHT PIPE THREAD
24 1 45078 OVERLAY CBS-2032e
25 3 73029 LEG, THERMOPLASTIC, 2.50"(63mm)
26 1 57006 FILL VALVE, S-53 120VAC
26 1 57017 FILL VALVE, S-53 220VAC
EXPORT
220V ONLY
27 1 24012 GASKET, S-53 FILL VALVE
28 1 31078 FITTING, S-53 FILL VALVE INLET
29 1 03074 BRACKET, S-53
30 4 82020 SCREW, S-53 FILL VALVE
31 1 31031 FITTING, 90 MALE ELBOW, 3/8 TUBE OD X 3/8 MPT
32 1 86040 CONNECTOR, CABLE CLAMP, 3/4"
33 1 102190 ASSEMBLY, DIGITAL TEMP. PROBE, 5.0" LG.
34 1 102139 ASSEMBLY, WATER LEVEL PROBE, CBS-2030'S
35 2 102195 ASSEMBLY, BUMPER, 2030e
36 2 25056 TUBE, 3/4"OD X 1/2"ID X 4"LG, BREW
37 1 25064 TUBE, 5/8"OD X 3/8"ID X 6.5"LG. HOT WATER
38 1 25055 TUBE, 5/8"OD X 3/8"ID X 12"LG DRAIN
39 1 25057 TUBE, 5/8"OD X 3/8"ID X 14 1/2"LG, COLD WATER
40 1 25058 TUBE 5/8"OD X 3/8"ID X 2.5"LG, HOT WATER FAUCET
41 1 25059 TUBE, 5/16"OD X 3/16"ID X 9 1/4"LG VENT
42 4 86038 CLAMP, HOSE, .670"-.780" DIA RANGE
43 2 86020 CLAMP, HOSE, .875"-.750" DIA RANGE
44 5 86007 CLAMP, HOSE, .593"-.656" DIA RANGE
45 1 25102 TUBE, 1/4"OD X 1/8"ID X 20" LG VENT HOT WATER VALVE
46 1 44004 LABEL GROUND
47 2 44024 LABEL, WARNING-HIGH VOLTAGE
48 1 01479 COVER, TOP CBS-2032 & 42
49 1 01463 COVER, UPPER BASE CBS-2032e
50 1 401219 WIRING DIAGRAM, CBS-2032e, 1PH, 3 WIRE + GR, 2 HEATERS
51 1 102191 ASSEMBLY, RIGHT COVER CBS-2030's
52 10 82053 SCREW, # 6-32 X 1/2" TRUSS HD PH
53 1 46027 LABEL, SPRAY HOUSING
54 1 46029 LABEL, POWER SWITCH
55 1 41016 LABEL, EXTRACTOR
57 2 101171 BREW BASKET ASSY., 13 X 5, DIA HOLE 0.218" (SEE FIG 6)
ADDITIONAL PARTS FOR CBS-2032s, NOT SHOWN ON DRAWING
2 101160 ASSEMBLY, BREW BASKET LOCK. 120 VAC
2 101174 ASSEMBLY, BREW BASKET LOCK. 220 VAC
EXPORT
220V ONLY
2 102207 ASSEMBLY, REED SWITCH
1 57043 VALVE, BYPASS RIGHT 120 VAC
57047 VALVE, DSV-11, 120 VAC (COIL, DIAPHRAGM, SPRING, & PLUNGER)
1 57076 VALVE, BYPASS RIGHT 220 VAC
EXPORT
220V ONLY
