Fetco CBS-2032E - Figure 5 - Spray Housing Assembly; Spray Housing Assembly, 120;220 VAC

22
Figure 5 – Spray Housing Assembly, 120 VAC, Part # 102080
Spray Housing Assembly, 220 VAC, Part # 102158 (EXPORT ONLY)
ITEM # QTY PART # DESCRIPTION
1 4 82112 #8 X 3/4'' PAN HD. PHIL. T.S. 18-8 S.S. SCREW
2 1 57047 VALVE ASSY., DSV-11, 120 VAC
2 1 57071 VALVE ASSY., DSV-11, 240 VAC
EXPORT
220V ONLY
3 1 57073 VALVE REBUILD KIT, DSV11
4 1 102082 SPRAY HOUSING ASSY.
5 1 24054 O-RING 4.237” I.D., #156
6 1 102081 SPRAY PLATE ASSY., 4 7/8" DIA.
