Fetco CBS-2032E - Figure 6 - Round Brew Basket Assembly; Figure 7 - Square Brew Basket Assembly

23
NOTE: The round and square brew baskets pictured below are not interchangeable. Use only the
type of brew basket that originally came with the brewer.
Figure 6 – Brew Basket Assembly, 13” X 5”, Part # 101171 (ROUND)
Figure 7 – Brew Basket Assembly, 13” X 5”, Part # 101175 (SQUARE)
COLOR BREW BASKET HANDLES
PART # DESCRIPTION
23169 BREW BASKET HANDLE, RED
23171 BREW BASKET HANDLE, GREEN
ITEM QTY PART # DESCRIPTION
1 1 9021 WIRE INSERT, 13 X 5
2 2 82118 HANDLE SCREW
3 1 23074 BREW BASKET HANDLE, BLACK
4 1 46011 WARNING LABEL
NOT
SHOWN
F002 PAPER FILTERS, 13” X 5”
500 PER CASE
ITEM QTY PART # DESCRIPTION
1 09022 WIRE INSERT, 13” X 5
2 1 23117 BREW BASKET HANDLE, BLACK
3 1 46011 WARNING LABEL
5 1 82096 HANDLE SCREW
8 1 57082 MAGNET
NOT
SHOWN
F002
PAPER FILTERS, 13” X 5”
500 PER CASE
COLOR BREW BASKET HANDLES
PART # DESCRIPTION
23106 BREW BASKET HANDLE, GREEN
23107 BREW BASKET HANDLE, ORANGE
23148 BREW BASKET HANDLE, RED
