23
Drawing 1101.00128.00 CBS-2131ASSEMBLY, 1gallon NO BYPASS, 2.3kW/120VAC
Ref# Qty Part number Description
1 1 1111.00030.00 WELDMENT BODY, CBS-2131
2 2 1024.00049.00 EDGE PROTECTOR, 7.00"LG, CBS-2130
3 3 1086.00004.00 BUSHING, SNAP, 1" MOUNTING HOLE
4 1 1024.00017.00 O'RING, 3.739" ID X 0.070" CS, 70 DURO, BUNA "N", FDA
5 1 1102.00183.00 SPRAY HOUSING ASSEMBLY, CBS-2130
6 4 1083.00010.00 WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
7 8 1084.00006.00 NUT, 8-32 18-8 HEX MACHINE SCREW
8 1 1102.00113.00 SWITCH, REED, ASSEMBLY
9 4 1029.00006.00 #4-40 NYLON FINGER NUT
10 1 1071.00010.00 FAUCET HPSC-BR-8 REGULAR HANDLE
11 1 1031.00003.00 FITTING, BARB 3/8'ID x 1/4" FPT
12 1 1057.00043.00 SOLENOID VALVE, SINGLE, 180 DEG, 24VDC
13 1
14 2 1083.00005.00 WASHER, M4 18-8 INTERNAL TOOTH LOCKWASHER
15 2 1082.00010.00 SCREW, M4x10 ZINC PLATED PAN PHILLIPS MACHINE
16 1 1102.00164.00 ADAPTER ASSY, 3/4" BSP X 1/4 SAE FLARE
17 1 1104.00043.00 TANK ASSY, 2300W/120VAC, CBS-2131, GROMMETS
18 1 1112.00163.00 WELDMENT TANK LOCK BRACKET, CBS-2100
19 4 1083.00011.00 WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
20 2 1082.00023.00 SCREW, #8-32 X 3/8 TRUSS HD PHIL., MACHINE
21 1 1102.00187.00 PUMP BRACKET AND HOLDER ASSEMBLY
22 9 1086.00003.00 UNICLAMP, 15.9 HOSE OD CLAMP
23 1 1025.00063.00 TUBE, 5/8'OD X 3/8"ID X 8.50"LG
24 1 1102.00181.00 ASSEMBLY BACK PANEL, CBS-2130
25 11 1082.00017.00 SCREW, # 6-32 X 1/2" TRUSS HD PHIL., MACHINE
26 1 1023.00147.00 PLUG, TANK SERVICE DRAIN FOR 18GA AND UP BODY
27 1 1024.00040.00 CARD PLUG, HWD-2100
28 1 1102.00190.00 ASSEMBLY FRONT PANEL, CBS-2100
29 4 1082.00058.00 SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
30 1 1102.00182.00 ASSEMBLY, LOCATOR CBS-2130
31 1 1082.00065.00 SCREW #8-32 X 1 1/2", FLAT HD PH, 18-8 SS
32 1 1023.00159.00 CORNER INSERT
33 1 1112.00168.00 WELDMENT, TOP COVER, CBS-2131
34 1 1402.00034.00 HARNESS, HIGH AMP, CBS-2131
35 1 1402.00035.00 HARNESS, LOW AMP, CBS-2131
36 1 B012280B1 BB ASSY, 13"X5", .280" DIA. HOLE, BLK HNDL
37 1 1024.00052.00 CONNECTOR, BREW PUMP
38 1 1086.00002.00 CLAMP, HOSE, SIZE "G" NYLON
39 1 1055.00001.00 PUMP, HOT LIQUID
40 1 1025.00012.00 TUBE, 5/16'OD X 3/16"ID X 11.00"LG
41 1 1025.00061.00 TUBE, 9/16'OD X 5/16"ID X 2.75"LG
42 1 1029.00002.00 FITTING, HOSE BARB TEE, SIZE 3/8" , NYLON
43 1 1025.00058.00 TUBE, 9/16'OD X 5/16"ID X 25.00"LG
44 1 1025.00060.00 TUBE, 9/16'OD X 5/16"ID X 3.25"LG
45 1 1083.00009.00 WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
46 1 1084.00010.00 NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
47 1 1025.00006.00 TUBE, VENT SUPPORT, 5/16" OD X 3/16" ID X 1/2" LG
48 1 1025.00064.00 TUBE, 1/2 OD X 1/4 ID X 9.00 LG
49 1 1013.00073.00 TUBE, 5/16" OD, 1" LONG
50 1 1046.00006.00 LABEL, WARNING, "HOT WATER FAUCET"
51 1 1044.00004.00 LABEL, DANGER, HIGH VOLTAGE
52 1 1046.00003.00 LABEL, CSD WARNING, 1.5" X 5.0"
53 4 1023.00163.00 LEG BODY, CBS-2130
54 4 1083.00021.00 WASHER, 1/4" SCREW SIZE, SPRING LOCK
55 4 1112.00158.00 WELDMENT, LEG ROD, CBS-2130
56 4 1021.00017.00 LEG INSERT THREADED, CBS-2130
