Fetco CBS-2131XTS - CBS-2132 XTS 1 Gallon Parts List; Component Breakdown

27
Drawing 1101.00150.00 CBS-2132 XTS 1 Gallon
Ref# Qty Part number Description
1 1 1111.00037.00 WELDMENT BODY, COMPLETE, CBS-2132
2 2 1024.00049.00 EDGE PROTECTOR, 7.00"LG, CBS-2130
3 2 1086.00004.00 BUSHING, SNAP, 1" MOUNTING HOLE
4 2 1024.00063.00 O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
5 2 1102.00203.00 ASSEMBLY, SPRAY HOUSING, DSVP11 DESIGN
6 8 1083.00010.00 WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
7 13 1084.00006.00 NUT, 8-32 18-8 HEX MACHINE SCREW
8 2 1102.00113.00 SWITCH, REED, ASSEMBLY
9 4 1029.00006.00 #4-40 NYLON FINGER NUT
10 1 1071.00010.00 FAUCET HPSC-BR-8 REGULAR HANDLE
11 1 1031.00003.00 FITTING, BARB 3/8'ID x 1/4" FPT
12 1 1057.00043.00 SOLENOID VALVE, SINGLE, 180 DEG, 24VDC
13 2 1083.00005.00 WASHER, M4 18-8 INTERNAL TOOTH LOCKWASHER
14 2 1082.00010.00 SCREW, M4x10 ZINC PLATED PAN PHILLIPS MACHINE
15 1 1102.00243.00 ADAPTER ASSY, 3/4" BSP x 1/4" NPT x 3/8" TUBE
16 1 1104.00052.00 TANK ASSY, 2 X 3.0kW/240V, CBS-2132 XTS (See Page 34)
17 5 1083.00011.00 WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
18 1 1025.00060.00 TUBE, 9/16'OD X 5/16"ID X 3.25"LG
19 10 1086.00003.00 UNICLAMP, 15.9 HOSE OD CLAMP
20 1 1029.00002.00 FITTING, HOSE BARB TEE, SIZE 3/8" , NYLON
21 1 1025.00058.00 TUBE, 9/16'OD X 5/16"ID X 25.00"LG
22 1 1025.00077.00 TUBE, 9/16 OD x 5/16 ID x 6.50 LG.
23 1 1025.00028.00 TUBE, 5/8"OD X 3/8"ID X 11"LG, HOT WATER VALVE, IN
24 12 1084.00011.00 NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
25 1 1102.00208.00 ASSEMBLY BACK PANEL, CBS-2132 AND 2142 (See Page 36)
26 13 1082.00017.00 SCREW, # 6-32 X 1/2" TRUSS HD PHIL., MACHINE
27 1 1023.00147.00 PLUG, TANK SERVICE DRAIN FOR 18GA AND UP BODY
28 1 1024.00040.00 CARD PLUG, HWD-2100
29 1 1102.00210.00 ASSEMBLY FRONT PANEL, CBS-2130, GRAVITY VERSION
30 6 1082.00058.00 SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
31 2 1102.00259.00 LOCATOR ASSEMBLY,L3S-10, GRAY, CBS-2130
32 2 1023.00221.00 ADAPTER FOR AIRPOT, GRAY, CBS-2130
33 2 1023.00159.00 CORNER INSERT
34 1 1001.00127.00 COVER, TOP CBS-2132 AND 2142
35 1 1001.00128.00 COVER, UPPER BASE, CBS-2132 AND 2142
36 1 1402.00037.00 HARNESS, HIGH AMP, CBS-2132 UL
37 1 1402.00038.00 HARNESS, LOW AMP, CBS-2132 GRAVITY
38 2 B014218BN2 BB ASSY Plastic, 13" X 5", ınˇ.218" HOLE, BRN PLUG
38 2 B012218B1 BB ASSY Stainless Steel, 13" X 5", ınˇ.
39 1 1083.00009.00 WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
40 1 1084.00010.00 NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
41 2 1025.00078.00 TUBE, 5/16 OD x 3/16 ID x 14.00 LG.
42 3 1023.00163.00 LEG BODY, CBS-2130
43 3 1083.00021.00 WASHER, 1/4" SCREW SIZE, SPRING LOCK
44 3 1112.00158.00 WELDMENT, LEG ROD, CBS-2130
45 3 1021.00017.00 LEG INSERT THREADED, CBS-2130
46 1 1046.00006.00 LABEL, WARNING, "HOT WATER FAUCET"
47 2 1046.00003.00 LABEL, CSD WARNING, 1.5" X 5.0"
48 2 1024.00065.00 CONNECTOR, SILICONE, TANK TO BREW VALVE
49 2 1086.00002.00 CLAMP, HOSE, SIZE "G" NYLON
50 1 1041.00002.00 LABEL , "CSD"
51 1 1041.00013.00 LABEL, XTS, 2130,2140 AND 2150 SERIES
52 1 1065.00002.00 CONNECTOR, COPPER LUG
53 1 1044.00012.00 LABEL GROUND CE
