Fetco CBS-2131XTS - Export CBS-2131, CE 3 kW;240 VAC, 3 L Parts List; Component Breakdown

33
Drawing 1101.00189.00 CBS-2131, CE 3kW/240VAC, 3L,
1 1 1111.00036.00 WELDMENT BODY, COMPLETE, CBS-2131
2 2 1024.00049.00 EDGE PROTECTOR, 7.00"LG, CBS-2130
3 1 1086.00004.00 BUSHING, SNAP, 1" MOUNTING HOLE
4 1 1024.00063.00 O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
5 1 1102.00203.00 ASSEMBLY, SPRAY HOUSING, DSVP11 DESIGN
6 4 1083.00010.00 WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
7 9 1084.00006.00 NUT, 8-32 18-8 HEX MACHINE SCREW
8 1 1102.00113.00 SWITCH, REED, ASSEMBLY
9 2 1029.00006.00 #4-40 NYLON FINGER NUT
10 1 1071.00010.00 FAUCET HPSC-BR-8 REGULAR HANDLE
11 1 1031.00003.00 FITTING, BARB 3/8'ID x 1/4" FPT
12 1 1057.00043.00 SOLENOID VALVE, SINGLE, 180 DEG, 24VDC
13 2 1083.00005.00 WASHER, M4 18-8 INTERNAL TOOTH LOCKWASHER
14 2 1082.00010.00 SCREW, M4x10 ZINC PLATED PAN PHILLIPS MACHINE
15 1 1102.00243.00 ADAPTER ASSY, 3/4" BSP x 1/4" NPT x 3/8" TUBE
16 1 1104.00056.00 TANK ASSY, 3.0kW/240V, CBS-2131 XTS (See Page 35)
17 5 1083.00011.00 WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
18 11 1084.00011.00 NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
19 1 1102.00213.00 ASSEMBLY, BACK PANEL, CBS-2131/41, CE (See Page 39)
20 12 1082.00017.00 SCREW, # 6-32 X 1/2" TRUSS HD PHIL., MACHINE
21 1 1023.00147.00 PLUG, TANK SERVICE DRAIN FOR 18GA AND UP BODY
22 1 1024.00040.00 CARD PLUG, HWD-2100
23 1 1102.00210.00 ASSEMBLY FRONT PANEL, CBS-2130, GRAVITY VERSION
24 5 1082.00058.00 SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
25 1 1102.00259.00 LOCATOR ASSEMBLY,L3S-10, GRAY, CBS-2130
26 1 1023.00159.00 CORNER INSERT
27 1 1001.00126.00 COVER, UPPER BASE, CBS-2131 AND 2141
28 1 1001.00125.00 COVER, TOP CBS-2131 AND 2141
29 1 1402.00041.00 HARNESS, LOW AMP, CBS-2131 XTS, CE/UL
30 1 1402.00042.00 HARNESS, HIGH AMP, CBS-2131 XTS, CE
31 1
B014218BN2 BB ASSY Plastic, 13" X 5", ınˇ.218" HOLE, BRN PLUG
31 1
B012218B1 BB ASSY Stainless Steel, 13" X 5", ınˇ.
32 1 1086.00002.00 CLAMP, HOSE, SIZE "G" NYLON
33 8 1086.00003.00 UNICLAMP, 15.9 HOSE OD CLAMP
34 1 1025.00060.00 TUBE, 9/16'OD X 5/16"ID X 3.25"LG
35 1 1029.00002.00 FITTING, HOSE BARB TEE, SIZE 3/8" , NYLON
36 1 1025.00058.00 TUBE, 9/16'OD X 5/16"ID X 25.00"LG
37 1 1025.00077.00 TUBE, 9/16 OD x 5/16 ID x 6.50 LG.
38 3 1083.00009.00 WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
39 1 1084.00010.00 NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
40 1 1025.00078.00 TUBE, 5/16 OD x 3/16 ID x 14.00 LG.
41 1 1046.00006.00 LABEL, WARNING, "HOT WATER FAUCET"
42 1 1046.00003.00 LABEL, CSD WARNING, 1.5" X 5.0"
43 4 1073.00008.00 FOOT, CBS-2130
44 4 1082.00066.00 SCREW, SOCKET HD. CAP 1/4-20 X 1/2"
45 1 1024.00065.00 CONNECTOR, SILICONE, TANK TO BREW VALVE
46 1 1025.00028.00 TUBE, 5/8"OD X 3/8"ID X 11"LG, HOT WATER VALVE, IN
47 1 1041.00002.00 LABEL , "CSD"
48 1 1041.00013.00 LABEL, XTS, 2130,2140 AND 2150 SERIES
49 1 1052.00029.00 EMI FILTER, TWO LINE 20A, 120/250 VAC
50 2 1084.00012.00 NUT, HEX, #6-32 MACHINE SCREW, 18-8 SS
51 1 1102.00238.00 ASSEMBLY POWER CORD, 16A/250VAC, EU1-16P PLUG
52 1 1065.00009.00 GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
53 1 1044.00012.00 LABEL GROUND CE
54 1 1023.00221.00 ADAPTER FOR AIRPOT, GRAY, CBS-2130
