Fetco GR-2.2 - Parts List - Figure 3 - GR-2.2 & GR-2.3

11
Parts List – Figure 3 – GR-2.2 & GR-2.3
Ref
GR 2.3
GR2.2
Part Number
Name
1
1
1
1111.00083.00
BODY WELDMENT, GR-2, CE VERSION
2
4
4
1029.00009.00
FASTENER, 9/32" HEAD DIA X .165" LG, PUSH IN
3
4
4
1073.00006.00
FOOT, GRINDER
4
8
8
1083.00019.00
WASHER, #10 SCREW SIZE, SPRING LOCK
5
4
4
1082.00031.00
SCREW, #10-32 X 5/8", PAN HD PHIL, MACHINE
6
1
1
1021.00005.00
ROD, VIBRATION DAMPENING, GR-2
7
1
1
1082.00018.00
SCREW, TRUSS HD. PHIL. SM, #8 X 1/2 LG.
8
2
2
1102.00304.00
SOLENOID ASSEMBLY, 230VAC, GR-2
9
4
4
1083.00026.00
WASHER, #10 SCREW SIZE, FLAT
10
4
4
1084.00014.00
NUT, HEX, #10-32, MACHINE SCREW
11
1
1
1067.00002.00
CAPACITOR, 230VAC VERSION, 12.5uF, 450VAC, 50-60Hz
12
1
1
1083.00025.00
WASHER, M8 SCREW SIZE, SPRING LOCK
13
1
1
1084.00018.00
NUT, HEX, M8 SCREW SIZE
14
1
1
1108.00029.00
ASSY. BOARD, CONTROL & SOFT. GR-1/2, 200-240VAC
15
4
4
1029.00006.00
NUT, FINGER, #4-40 NYLON
16
1
1
1402.00010.00
ELECTRICAL HARNESS, GR 2.3
17
2
2
1023.00044.00
MANIFOLD, GR-2
18
4
4
1083.00010.00
WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
19
4
4
1082.00017.00
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
20
1
-
1045.00007.00
OVERLAY, GR-2.3
20
-
1
1045.00009.00
OVERLAY, GR-2.2
21
6
4
1058.00007.00
SWITCH, START ROCKER, MOMENTARY, 250VAC
22
1
1
1058.00052.00
POWER SWITCH, DPST, 10A/250VAC, GREEN
23
2
2
1102.00033.00
HOPPER, ASSEMBLY, GRF-2.3
24
1
1
1102.00185.00
GRINDING MOTOR AND PLATE ASSY, 230V/50Hz
25
2
2
1083.00022.00
WASHER, 3/8" SCREW SIZE, FLAT
26
2
2
1083.00020.00
WASHER, 3/8 SCREW SIZE, SPRING LOCK
27
2
2
1082.00032.00
SCREW, 3/8"-16 X 3/4" LG, HEX HEAD CAP
28
1
1
1401.00131.00
WIRING DIAGRAM, GR-2, CE
29
1
1
1046.00009.00
LABEL "GR PROGRAMMING"
30
1
1
1112.00023.00
BASE COVER WELDMENT, GR/GRF
31
10
10
1082.00033.00
SCREW, PAN HD PHIL. MACH., W/DUAL WASHER, #6-32x3/8LG.
32
1
1
1102.00023.00
COVER, GRINDER SERVICE ASSEMBLY, W/O RAILS
33
1
1
1001.00035.00
COVER, REAR, GR-2
34
1
1
1023.00041.00
HOLDER, BREW BASKET, GR-1/2
35
1
1
1043.00036.00
TEMPLATE, SN LABEL, FETCO PRODUCTS
36
1
1
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
37
2
2
1083.00016.00
WASHER, #8 SCREW SIZE, FLAT
38
2
2
1083.00011.00
WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
39
3
3
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
40
1
1
1044.00013.00
LABEL EQUIPOTENTIALITY, CE
41
1
1
1044.00012.00
LABEL GROUND, CE
42
1
1
1052.00051.00
EMI FILTER, 10A, 120/250VAC, 50/60Hz
43
2
2
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
44
2
2
1081.00061.00
STANDOFF, 1/4 HEX x 1 1/4 LG., #6-32 THREAD
45
1
1
1402.00096.00
HARNESS, GR-1/GR-2, CE VERSION ADDITION
46
3
3
1064.00030.00
CRIMP CONNECTOR, PRE-INSULATED, 22-14 AWG WIRE RANGE
47
1
1
1064.00032.00
CRIMP CONN., PRE-INSULATED, NC-8
Not Shown- All Types
1102.00369.00
POWER CORD ASEMBLY, 10A/250VAC, CE VERSION
Drawings: GR2.3: 1101.00334.00 GR2.2: 1101.00337.00
