Parts List – Figure 2 – GR-1.2 & GR-1.3
Ref
GR 1.3
GR1.2.2
Part Number
Name
1
1
1
1111.00084.00
WELDMENT BODY, COMPLETE, GR-1, CE
2
1
1
1021.00005.00
ROD, VIBRATION DAMPENING, GR-2
3
1
1
1082.00018.00
SCREW, TRUSS HD. PHIL. SM, #8 X 1/2 LG.
4
4
4
1073.00006.00
FOOT, GRINDER
5
4
4
1083.00019.00
WASHER, #10 SCREW SIZE, SPRING LOCK
6
4
4
1082.00031.00
SCREW, #10-32 X 5/8", PAN HD PHIL, MACHINE
7
1
1
1108.00029.00
ASSY. BOARD, CONTROL & SOFT. GR-1/2, 200-240VAC
8
4
4
1029.00006.00
NUT, FINGER, #4-40 NYLON
9
1
1
1402.00010.00
ELECTRICAL HARNESS, GR 2.3
10
1
1
1112.00023.00
BASE COVER WELDMENT, GR/GRF
11
1
1
1046.00009.00
LABEL "GR PROGRAMMING"
12
8
8
1082.00033.00
SCREW, PAN HD PHIL. MACH., W/DUAL WASHER, #6-32x3/8LG.
13
1
1
1402.00096.00
HARNESS, GR-1/GR-2, CE VERSION ADDITION
14
1
1
1102.00185.00
GRINDING MOTOR AND PLATE ASSY, 230V/50Hz
15
2
2
1083.00022.00
WASHER, 3/8" SCREW SIZE, FLAT
16
2
2
1083.00020.00
WASHER, 3/8 SCREW SIZE, SPRING LOCK
17
2
2
1082.00032.00
SCREW, 3/8"-16 X 3/4" LG, HEX HEAD CAP
18
1
1
1023.00148.00
FUNNEL, HOPPER, GR-1
19
2
2
1083.00010.00
WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
20
2
2
1082.00023.00
SCREW, #8-32 X 3/8 TRUSS HD PHIL., MACHINE
21
1
1
1067.00002.00
CAPACITOR, 230VAC VERSION, 12.5uF, 450VAC, 50-60Hz
22
1
1
1083.00025.00
WASHER, M8 SCREW SIZE, SPRING LOCK
23
1
1
1084.00018.00
NUT, HEX, M8 SCREW SIZE
24
1
-
1045.00017.00
OVERLAY, GR-1.3
24
-
1
1045.00016.00
OVERLAY, GR-1.2
25
3
2
1058.00007.00
SWITCH, START ROCKER, MOMENTARY, 250VAC
26
1
1
1058.00052.00
POWER SWITCH, DPST, 10A/250VAC, GREEN
27
1
1
1102.00023.00
COVER, GRINDER SERVICE ASSEMBLY, W/O RAILS
28
1
1
1028.00001.00
WINDOW, GR-1
29
1
1
1023.00041.00
HOLDER, BREW BASKET, GR-1/2
30
1
1
1044.00012.00
LABEL GROUND, CE
31
2
2
1083.00016.00
WASHER, #8 SCREW SIZE, FLAT
32
2
2
1083.00011.00
WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
33
3
3
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
34
1
1
1052.00051.00
EMI FILTER, 10A, 120/250VAC, 50/60Hz
35
2
2
1083.00009.00
WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
36
2
2
1081.00061.00
STANDOFF, 1/4 HEX x 1 1/4 LG., #6-32 THREAD
37
1
1
1102.00369.00
ASS'Y. POWER CORD, 10A/250VAC, CE VERSION
38
1
1
1001.00020.00
COVER, REAR, GR-1/GRF-2
39
1
1
1401.00132.00
WIRING, GR-1 (L-N-PE), CE
40
1
1
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
41
1
1
1044.00013.00
LABEL EQUIPOTENTIALITY, CE
42
1
1
1043.00036.00
TEMPLATE, SN LABEL, FETCO PRODUCTS
43
3
3
1064.00030.00
CRIMP CONNECTOR, PRE-INSULATED, 22-14 AWG WIRE RANGE
44
3
3
1064.00032.00
CRIMP CONN., PRE-INSULATED, NC-8
Not Shown- All Types
1102.00369.00
POWER CORD ASEMBLY, 10A/250VAC, CE VERSION
Drawings: GR1.3: 1101.00335.00 GR1.2: 1101.00338.00
