Fetco MBS-1221 - MBS-122 S Short Parts List

Go to fetco.com for the latest versions of all information Page 21 User Guide & Operator instructions MBS-1221 P202Re0August 2021
ITEM
Qty
PART NO
DESCRIPTION Drawing number 1101.00589.00 MBS-122S SHORT ONLY
1
1
1111.00113.00
WELDMENT BODY, MBS-122S, SHORT
2
7
1084.00051.00
NUT, HEX LOCKWASHER, #8-32, 18-8 ST. STL.
3
1
1082.00082.00
SCREW, PHILLIP HD., 8-32 THREAD
4
4
1073.00021.00
FOOT, RUBBER, 1/4-20
5REF
1
Reference
ELECTRICAL COMPONENT LATTICE, CBS-1200
5-1
1
1023.00360.00
ELECTRICAL MOUNTING LATTICE, AIR POT
5-2
1
1052.00023.00
EUROSTRIP HE16 TERM. BLOCK, 4 POLE, 63 AMP, 18-8 AWG
5-3
2
1082.00056.00
SCREW, #8-11 X 1" PAN HD PHIL, THREAD FORMING
5-4
1
1058.00024.00
SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
5-5
1
1057.00043.00
SOLENOID VALVE, 5.5L/min, 180 DEG, 24VDC
5-6
2
1082.00010.00
SCREW, PAN HD. PHIL. MACH., M4x10 ZINC-PLATED
5-7
1
1058.00055.00
USB CONNECTOR
5-8
1
1052.00001.00
POWER SUPPLY, 90-264VAC/24VDC, 1.8A
6
1
1057.00080.00
FILL VALVE, SINGLE, 180 DEG, 24VDC, (2.1-2.5L/min INLET FLOW)
7
2
1082.00010.00
SCREW, PAN HD. PHIL. MACH., M4x10 ZINC-PLATED
8
1
1065.00009.00
GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
9
1
1044.00012.00
LABEL GROUND, CE
10
1
1102.00485.00
ASSEMBLY, FRONT PANEL, MBS-1220
11
3
1023.00361.00
SPACER, UNTHREADED, 1/2"OD X 3/8" LONG
12
3
1082.00115.00
SCREW, #6 x 3/8" LG., SLOTED HEX HD. WASHER
13
1
1071.00055.00
FAUCET, HOT WATER, PSC-BR-8, WITH FLAT AND STEM
14
1
1084.00048.00
JAM NUT, 1/2-20 UNF, NICKEL PLATED BRASS
15
1
1102.00113.00
SWITCH, REED, ASSEMBLY
16
2
1029.00006.00
NUT, FINGER KNURLED, #4-40
17
1
1102.00203.01
ASSEMBLY, SPRAY HOUSING, DSVP11 DESIGN, NO VENT
18
1
1024.00063.00
O-RING, 3 15/16" x 3/32" CS, DASH # 154, BUNA-N, DURO-A50
19
4
1083.00010.00
WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
20
4
1084.00006.00
NUT, 8-32 18-8 HEX MACHINE SCREW
21
1
1025.00013.00
TUBE, 5/8"OD X 3/8"ID X 4.5"LG
22
6
1086.00003.00
UNICLAMP, 15.9 HOSE OD CLAMP
23
1
1025.00110.00
TUBE DRAIN, 5/8"OD X 3/8"ID X 10" LG.
24
1
1025.00058.00
TUBE, 9/16"OD X 5/16"ID X 25.00"LG
25
1
1025.00061.00
TUBE, 9/16'OD X 5/16"ID X 2.75"LG
26
1
1086.00002.00
CLAMP, HOSE, SIZE "G" NYLON
27
14
1084.00011.00
NUT, CLIP ON (J-NUT), #6-32, 22-20 GA., BLK-PH FINISH
28
1
1001.00455.00
TOP COVER, MBS/TBS-1200, LARGE
29
1
1112.00550.00
WELDMENT FRONT COVER, MBS-122S, SHORT
30
1
1023.00397.00
FAUCET, DILUTION, SINGLE, BLACK
31
2
1082.00058.00
SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
32
1
1023.00183.00
FITTING, ELBOW, GROMMET, .375"
33
1
1025.00022.00
TUBE, 5/8"OD X 3/8"ID X 1.25LG., BY-PASS
34
1
1025.00071.00
TUBE, 9/16"OD x 5/16"ID x 16.75"LG.
35
14
1082.00017.00
SCREW, TRUSS HD. PHIL. MACHINE, # 6-32 X 1/2 LG.
36
1
1046.00003.00
LABEL, CSD WARNING, 1.5" X 5.0"
37
1
1046.00035.00
LABEL, WARNING "TO REDUCE RISK OF ELECTRIC SHOCK OR FIRE"
38
1
1086.00009.00
CLAMP, 3/4" MAX TUBE OD FLOW CONTROL
39
1
1041.00033.00
BLACK EXTRACTOR PLUS LABEL, LASER ENGRAVED
40
1
1102.00488.00
ASSEMBLY, DUAL WATER INLET CONNECTOR
41
1
1402.00113.00
WIRE HARNESS ADDITION, POWER SUPPLY GROUND
42
1
1402.00118.00
WIRE HARNESS, MBS-1221, HIGH AMP
43
1
1402.00119.00
WIRE HARNESS, MBS-1221, LOW AMP
44
1
B015280BN2BK
BREW BASKET ASSY BLACK, 16" X 6", 0.280" DIA HOLE, BROWN PLUG
45
1
B015140G2BK
BREW BASKET ASSY BLACK, 16" X 6", 0.140" DIA HOLE, GREEN PLUG
46
1
1104.00190.00
TANK ASSEMBLY, CBS/MBS-1221, 1.7kW/120VAC OR 3.0kW/240VAC
47
1
1086.00008.00
CONNECTOR, CLAMP, NON-METALLIC CABLE, 3/4"
48
1
1063.00016.00
POWER CORD, 120VAC W/NEMA 5-15P PLUG
49
1
1102.00219.00
ASSEMBLY, BB LOCKER, 24VDC
50
2
1083.00011.00
WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
51
2
1084.00010.00
NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
52
1
1023.00399.00
HOT WATER PLUG & CONNECTOR
53
1
1023.00147.00
PLUG, TANK SERVICE DRAIN FOR 18 GA AND UP BODY
