Fetco MBS-1221 - Specifications and Requirements

Go to fetco.com for the latest versions of all information Page 2 User Guide & Operator instructions MBS-1221 P202Re0August 2021
Specifications and Requirements
Water Requirements:
Electrical: Supplied with 120V cord & plug
Water inlet fitting is a 1/4 inch male flare
User adjustable to 220-240 volt terminal block
Pressure: 20-75 psig, (138-517kPa) 1½gpm/(5.7lpm)
For Iced tea: brewer is factory calibrated to a non-fluctuating
stable water supply pressure at 45 psi.
Tank Temperature, as set by factory:
200°F (93°C) inside water tank (at sea level)
Iced Tea Batch Temperature-user adjustable
200°F-207°F-/ 93°-98°C
Water supply: (Optimal) 100-150TDS
All beverage equipment must use filtered water
Brew Volume-Coffee: Full Batch 2.20 liters
User adjustable to up to 0.85 gallon/3.25 liters per brew
Iced Tea Dilution Ratio: 1:4 factory set brew to water
Factory setting adds 2.4 gallons of cold water to 0.6 gallon
brew for a 1:4 ratio Iced tea
(2.3liter brew/9.1 liter dilution)
Dilution volume is user adjustable from 0-4Gal;0-15.2L
Brew Volume-Iced Tea: Full Batch 11.40 liters/3 gallons
User adjustable to up to 4.9 gallon/18.7 liters per brew
Brew batch and dilution ratio user adjustable
Total Brew Cycle—Factory default setting (Batch 1): 5 minutes=[3:30 minute brew time + 1:30 minute drip delay]
Iced Tea-(Batch 3) 4:30 minutes=[3:00 minute brew time + 1:30 minute drip delay] Batch 2 may be set for either
Brew-Process parameters are user controllable for: Brew Volume, Brew Time, Prewet Percent and Delay,
Drip Delay, Tea Batch Temperature, Dilution Volume and Dilution Timing (with brew or after brewing)
Electrical Specifications for domestic-dual voltage Standard height with brew shelf
SKU
Model description
Electrical
Connection
Brew Basket
Heater
Configuration
Voltage KW
Amp
Draw
Brew Volume/Hour
M1221US-1A117-P
M001
NEMA 15-5P
Plastic tea
Metal coffee
1 X 1.7 kW 120 1.7 14.7 4.4 gal/16.5 liters
M1221US-1A117-M
M001
NEMA 15-5P
Metal tea
Plasic coffee
1 X 1.7 kW 120 1.7 14.7 4.4 gal/16.5 liters
M1221US-1X117-PM001
Domestic-Dual Voltage
NEMA 15-5P
Terminal Block
Plastic tea
Plastic coffee
1 X 1.7 kW
1 X 3.0 kW
100-120
200-240
1.3-1.8
2.2-3.1
12.3-14.7
10.9-13.0
4.4 gal/16.5 liters
6-7 gal/22-21 liters
M1221US-1X117-MM001
Domestic-Dual Voltage
NEMA 15-5P
Terminal Block
Plastic tea
Metal coffee
1 X 1.7 kW
1 X 3.0 kW
100-120
200-240
1.3-1.8
2.2-3.1
12.3-14.7
10.9-13.0
4.4 gal/16.5 liters
6-7 gal/22-21 liters
Electrical Specifications for domestic-dual voltage Short version - no brew shelf
SKU
Model description
Electrical
Connection
Brew Basket
Heater
Configuration
Voltage KW
Amp
Draw
Brew Volume/Hour
M122SUS-1X117-PM001
Domestic-Dual Voltage
NEMA 15-5P
Terminal Block
Plastic tea
Plastic coffee
1 X 1.7 kW
1 X 3.0 kW
100-120
200-240
1.3-1.8
2.2-3.1
12.3-14.7
10.9-13.0
4.4 gal/16.5 liters
6-7 gal/22-21 liters
Factory supplied with 120 volt NEMA 5-15 cord and plug. Dual voltage brewers may be field converted to 200-240 volts-see pages 13 and 19
International
SKU
Electrical
Connection
Brew Basket
Heater
Configuration
Voltage KW
Amp
Draw
Brew Volume/Hour
M1221IN-1B130-PM005 CEE 7/7
Plastic tea
Plastic coffee
1 X 3.0 kW 200-240 2.1-3.0 10.9-13.0 4.4 gal/16.5 liters
M1221NM-1X117-PM001
DUAL VOLTAGE
NEMA 15-5P
Terminal Block
Plastic tea
Plastic coffee
1 X 1.7 kW
1 X 3.0 kW
100-120
200-240
1.3-1.8
2.2-3.1
12.3-14.7
10.9-13.0
4.4 gal/16.5 liters
6-7 gal/22-21 liters
M1221CE-1B130-PM005 CEE 7/7
Plastic tea
Metal coffee
1 X 1.7 kW 230 2.8 12.5 4.4 gal/16.5 liters
M1221CE-1B130-PM006 UK1-13P
Plastic tea
Metal coffee
1 X 1.7 kW 230 2.8 12.5 4.4 gal/16.5 liters
Export Only 250V 13 A
BS 1363A UK
G
W
NEMA 5-15P
Plug Configuration
Export Only 250V 16 A
“Schuko" CEE 7/7 PLUG
