FlameSpec IR3-H2-HD User Manual
F140V0020.03
For more information & Technical support: (+1) 714-671-8500 · support@fg-detection.com 9
Figure 3: Detector on Tilt Mount – Side View
ITEM
NO.
ITEM NAME
1
TILT MOUNT ASSEMBLY
2
HOLDING PLATE
3,4
MOUNTING HEX SCREWS M8 AND LOCK WASHERS
5
HEX SOCKET LOCKING SCREW M8
6
HEX SOCKET LOCKING SCREW M12
