5 Operation
The FlameSpec-IR3-H2-HD is a triple-IR flame detector that includes a built-in high-definition video camera
module. The video module automatically records video of alarm events, and can provide live video of the
detection zone to a screen in the control room.
The detector is ready for detecting fire approximately 30 seconds after power up. During this startup time the
LED flashes Yellow. If the startup is successful, the indication LED turns to green, the 0-20mA indicates 4mA
and the fault relay is closed. The video module starts operating approximately 2 minutes after power up.
Detector configuration settings can be changed as described in section 0.
To restart the detector, turn off and then turn on the power.
5.1 Output Signals
The detector has the following output signals:
▪ Current output (0–20mA)
▪ Relays (Fault and Alarm)
▪ RS-485
▪ Tri-color LED
TABLE 4: OUTPUT SIGNALS
