6 Specifications
6.1 Fire Detection
• Detection time and distance:
o 40ms - for fast fire burst or explosion
o 1.5s - for 32″ (0.8m) hydrogen fire at 0–100 ft. (0–20m)
o 4s for 32″ (0.8m) hydrogen fire at 66–100 ft. (20–30m)
• Field of view: 90° Horizontal, 75° Vertical
• Time Delay: 0-30 seconds (adjustable)
• Built-in test: Automatic and Manual
6.2 Video functionality
• HD Video allowing clear imaging of fire and people at 100ft. (30m) distance.
• Video recording of alarm events 1 minute before and up to 3 minutes after the flame is
detected.
• System integration protocol: ONVIF (Open Network Video Interface Forum) Profile S
6.3 Electrical Specifications
• Operating Voltage: 24 VDC nominal (18-32 VDC)
• Current Consumption:
o Standby 180mA
o Maximum 250mA all systems in operation (including window heater)
• Cable Entries: 2x conduit entries 3/4” 14NPT or M25x1.5
• Wiring: 12-20AWG (2.5-0.35mm
2
)
6.4 Outputs
• Relays: Volt-free contacts rated 2A at 30 VDC
o Alarm: Normally open and normally closed
o Fault
The FAULT relay will normally be energized and the contact will be closed during normal operation of the
detector. The contact will be open at fault condition or low voltage.
