Protected device Fuse Ampere
TO: Engine compartment fusebox – B: Optional wiring module 1
(*) –
C: Optional wiring module 2
Webasto control unit F61 30
Passenger compartment
fan with Webasto
F62 20
Trailer hook socket F63 20
Headlight washers F64 30
Trailer control unit F65 15
Trailer control unit F66 15
Trailer hook socket F67 20
(*) Only for 2.3 130/150 Multijet 2 versions
158
IN AN EMERGENCY
