Fiat PANDA 2016 - Page 149

Versions
0.9 TwinAir 60 HP
(*)
0.9 TwinAir 65 HP
0.9 TwinAir Turbo 80 HP
(*)
Engine code 312A6000 312A4000 312A5000
Cycle Otto Otto Otto
Number and position of cylinders 2 in line 2 in line 2 in line
Piston bore and stroke (mm) 83.5 × 88 83.5 × 88 80.5 × 86
Total displacement (cm³) 964 964 875
Compression ratio 11.1: 1 11.1: 1 10: 1
Maximum power (EC) (kW) 44 48 59
Maximum power (EEC) (HP) 60 65 80
corresponding engine speed (rpm) 6250 6250 5500
Maximum torque (EC) (Nm) 88 88 145
Maximum torque (EC) (kgm) 8.9 8.9 14.8
corresponding engine speed (rpm) 3500 3500 1900
Spark plugs NGK T20182U NGK LKR7DI-12 NGK PLKR9C8
Fuel
Unleaded petrol 95 R.O.N.
(EN 228 specifications)
Unleaded petrol 95 R.O.N.
(EN 228 specifications)
Unleaded petrol 95 R.O.N.
(EN 228 specifications)
(*) For versions/markets, where provided
147
