Fiat PANDA 2016 - Engine

ENGINE
Versions 1.2 8V 69 HP 1.2 8V 69 HP LPG
Engine code 169A4000 169A4000
Cycle Otto Otto
Number and position of cylinders 4 in line 4 in line
Piston bore and stroke (mm) 70.8 × 78.86 70.8 × 78.86
Total displacement (cm³) 1242 1242
Compression ratio 11.1: 1 11.1: 1
LPG Petrol
Maximum power (EC) (kW) 51 51 51
Maximum power (EEC) (HP) 69 69 69
corresponding engine speed (rpm) 5500 5500 5500
Maximum torque (EC) (Nm) 102 102 102
Maximum torque (EC) (kgm) 10.4 10.4 10.4
corresponding engine speed (rpm) 3000 3000 3000
Spark plugs
NGK ZKR7A-10 or
CHAMPION RA8MCX4
NGK ZKR7AI-8
Fuel
Unleaded petrol 95 R.O.N.
(EN 228 specifications)
LPG for motor vehicles
(EN589 Specification)
Unleaded petrol 95 R.O.N.
(EN 228 specifications)
146
TECHNICAL DATA
