Fiat PANDA 2016 - Page 151

Versions
0.9 TwinAir Turbo 90 HP
(*)
1.3 16V Multijet 95 HP 1.3 16V MultiJet 80 HP
Engine code 312A7000
312B1000 / 330A1000(°) 312B2000 / 225A2000 (°°)
Cycle Otto Diesel Diesel
Number and position of cylinders 2 in line 4 in line 4 in line
Piston bore and stroke (mm) 80.5 × 86.0 69.6 × 82 69.6 × 82
Total displacement (cm³) 875 1248 1248
Compression ratio 10: 1 16.8: 1 16.8: 1
Maximum power (EC) (kW)
66.2 / 57
(**)
70 59
Maximum power (EEC) (HP)
90 / 77.5
(**)
95 80
corresponding engine speed (rpm) 5500 3750 3750
Maximum torque (EC) (Nm)
145 / 100
(**)
200 200
Maximum torque (EC) (kgm)
14.8 / 10.2
(**)
20.4 20.4
corresponding engine speed (rpm)
1900 / 2000
(**)
1500 1500
Spark plugs NGK ILKR9G8 - -
Fuel
Unleaded petrol 95 R.O.N.
(EN 228 specifications)
Diesel for motor vehicles
(EN590 Specification)
Diesel for motor vehicles
(EN590 Specification)
(*) For versions/markets, where provided
(°) 4x4 and Cross Versions
(°°) 4x4 versions
(**) With ECO button pressed
149
