FIBARO FGMS-001 User Manual

10
ZWAVE RANGE TEST
#7: Z-Wave range test
The Motion Sensor has a built in Z-Wave network main controller’s
range tester.
Follow the below instructions to test the main controller’s range:
1. Open the cover.
2. Press and hold the B-button.
3. Wait for visual indicator to glow violet (1st menu position).
4. Release the B-button.
5. Click the B-button to conrm selection.
6. Visual indicator will indicate the Z-Wave network’s range (range
signalling modes described below).
7. To exit Z-Wave range test, press the B-button briey.
Z-Wave range tester signalling modes:
Visual indicator pulsing green - the Motion Sensor attempts to es-
tablish a direct communication with the main controller. If a direct
communication attempt fails, the device will try to establish a routed
communication, through other modules, which will be signalled by
visual indicator pulsing yellow.
Visual indicator glowing green - the Motion Sensor communicates
with the main controller directly.
Visual indicator pulsing yellow - the Motion Sensor tries to estab-
lish a routed communication with the main controller through other
modules (repeaters).
Visual indicator glowing yellow - the Motion Sensor communicates
with the main controller through the other modules. After 2 seconds
the device will retry to establish a direct communication with the
main controller, which will be signalled with visual indicator pulsing
green.
Visual indicator pulsing violet - the Motion Sensor does communi-
cate at the maximum distance of the Z-Wave network. If connection
proves successful it will be conrmed with a yellow glow. It’s not rec-
ommended to use the device at the range limit.
Visual indicator glowing red - the Motion Sensor is not able to con-
nect to the main controller directly or through another Z-Wave net-
work device (repeater).
CAUTION
To make Z-Wave range
test possible, the de-
vice must be added
to the Z-Wave control-
ler. Testing may stress
the network, so it is
recommended to per-
form the test only in
special cases.
!
NOTE
Communication mode
of the Motion Sensor
may switch between
direct and one using
routing, especially if
the device is on the
limit of the direct
range.
i

FIBARO FGMS-001 Specifications

General

Sensor type	-
Connectivity technology	Wireless
Maximum range	50 m
Battery type	CR123A
Certification	LVD 2006/95/WE, EMC 2004/108/WE, R&TTE 1999/5/WE, RoHS II
Product color	White
Operating temperature (T-T)	0 - 40 °C
