7
OPERATING THE DEVICE
#5: Operating the device
Controlling the Motion Sensor with FIBARO Home Center controller:
The Motion Sensor has a bulit-in motion detector, temperature sensor
and light intensity sensor, which make it a multi-channel device. In the
Home Center interface it will be presented as three devices.
Controlling the Motion Sensor using the B-button:
The Motion Sensor is equipped with a B-button, which allows to use
the menu and additionally perform the following actions:
1x click: wake up the device or select the desired menu option (if
menu is active)
3x click: add/remove the device to/from a Z-Wave network
Holding: enter/navigate through the menu
Visual indications:
The Motion Sensor is equipped with a LED diode, signalling sensor’s
operating modes and alarms. In addition the visual indicator may in-
form of the Z-Wave network range and the current temperature.
Visual indicator signalling modes:
1. Motion Alarm colour will vary depending on the temperature. The
colour and the signalling mode can be set in parameter 80.
2. Tamper alarm is signalled with an alternating blinking in LAPD
colours (red - blue - white).
3. The Z-Wave Node Info command frame is signalled with glowing in
blue. Node Info command frame is sent each time the device wakes up.
4. Menu position is signalled with assigned illumination colour.
Waking up the Motion Sensor:
The Motion Sensor needs to be woken up to receive information on new
congurations from the controller, like parameters and associations.
To wake up the sensor manually triple click the B-button located in-
side the housing.
Menu:
Menu allows to perform Z-Wave network actions. In order to use menu:
1. Press and hold the B-button.
2. Wait for the device to indicate desired position with a colour:
• VIOLET - Z-Wave network’s range test
• YELLOW - device reset
3. Release the B-button.
4. Click the B-button to conrm selection.
