FIBARO Smoke Sensor User Manual

Installation and Operation Guide
Smoke Sensor Page | 13
04. SENSOR INSTALLATION
Installing the Smoke Sensor:
1. As before, ensure that the Smoke Sensor is near to the Active SmartHome
Gateway, as the process can ONLY be carried out within the direct range of
the Active SmartHome Gateway.
2. Test the Z-Wave network range by performing a Walk Test ensuring the
device is within range (see section 4.1.).
3. The Smoke Sensor must have been added to Active SmartHome Portal
first (see section 3).
4. If the sensor is to be hard-wired to a power source, drill holes in the
sensor’s cover (Fig. 08).

FIBARO Smoke Sensor Specifications

General

Sensor Type	Photoelectric
Battery Type	CR123A
Wireless Technology	Z-Wave
Operating Temperature	0°C to 55°C
Dimensions	65 x 28 mm
Alarm Sound Level	85 dB
Radio Frequency	868.4 MHz (EU) / 908.4 MHz (US)
Humidity Range	0% to 93% (non-condensing)
Range	Up to 50 meters outdoors
Sensitivity	EN 14604:2005
Certifications	EN 14604
