G510 Hardware User Manual Page
10
of
42
Serial communications interfaces
SIM card port
Real Time Clock (RTC) subsystem
Analog Block
Power management inside
PLL generates 624MHz from 26MHz
Analog audio interface management
GSM Transceiver Block
G510 Q50-00 supports GSM850/900/1800/1900 bands
RF receiver, which includes LNAs, Mixers, PLL, I/Q outputs and buffers
Signal processing IC for transmit and receive GSM data processing
RF FEM control , which includes RFPA and antenna switch
3.2 Operating Modes
The module has many operating modes and different modes has different status. The operating
modes as listed below:
Operating Modes
Description
Features
Not Powered
VBAT & VBACKUP supply is
disconnected.
The module is off.
Any signals connected to the interface
connector must be set low or tri-state.
Power off Mode
Valid VBAT supply but not power on.
After reset module, VBCAKUP output
and VDD is off.
The module MCU/BB/RF is Off.
The PMU is operating in RTC mode.
Any signals connected to the interface
connector must be set low or tri-state.
RTC Mode
Power off mode
VBAT supply is disconnected. But
valid VBACKUP supply
The module MCU/BB/RF is Off.
The PMU is operating in RTC mode.
Any signals connected to the interface
