Fibocom G510 Hardware User Manual

G510 Hardware User Manual Page
8
of
42
The G510 is extremely compact in size with a slim mechanical design, which makes it space saving on
the application board and easily fitted into any board design.
The advanced power supply management significantly reduces power consumption to a necessary
minimum and prolongs battery life.
2.2 Specifications
Product Features
Operating Bands
G510-Q50-00: Quad Band 850/900/1800/1900 MHz;
G510-A20-00: Dual Band 900/1800MHz
Operating Voltage
3.3 – 4.5 V (4.0V is recommended)
Tx power
2 W, 850/900 MHz
1 W, 1800/1900 MHz
Rx Sensitivity (Typical Value)
850/900MHz: -109dBm
1800/1900MHz: -108dBm
Dimensions
20.2mm x 22.2mm x 2.5 mm
Weight
<2.5g
Mounting
LCC
Environmental
Operating Temperature
-40°C to +85°C
Storage Temperature
-40°C to +85°C
Interfaces
SIM Card
External SIM connectivity
1.8V / 3.0 V
Serial Ports
3 UART ports: UART1, UART2 and HOST UART
Baud Rate Range: from 2400 bps to 460800 bps
Data Features
GPRS
Multi-slot class 10 (4Rx / 2 Tx / 5 Sum)
Coding scheme CS1-CS4
Class B
