4. DESCRIPTION OF THE MACHINE
Description of the machine
1. Metal three tooth blade /
semi-automatic string trimmer head
2. Trimmer line cutter
3. Protective safety guard
4. Split shaft coupler
5. Handle mount
6. Throttle trigger lock
7. Throttle trigger
8. Power switch
9. Throttle safety switch
10. Engine
11. Fuel tank cap
12. Fuel tank
13. Shoulder strap hitch
14. Choke control lever
15. Fuel primer bulb
Included contents:
Brush cutter, string trimmer head, metal three tooth blade, shoulder strap, calibrated fuel mixing container,
tool set
