Install the seatpost battery
① Open the seat clamp, take off the EVA protective
cotton, insert the seatpost battery.
③ Close the seat clamp till the screws on the seat clamp is aligned, to finish the completed installation of seatpost battery.
② Adjust the seatpost battery to suitable height, the
recommended height is when the saddle is level with
the user’s pelvis when standing naturally.
(Caution: Do not adjust the height beyond the maximum
and minimum heights on the battery holder scale.)
(Caution: Using the coded lock and turn on the power, to check whether the battery is properly installed. If the power can
be turned on normally,means the installation is successful. Please refer to P13 for details of coded lock operation.)
8
