2.1 Installation guide
Unfold the stem
The basic installation of the bike has been completed before leaving the factory. After receiving the bike, you only need
to unfold the stem, install the seatpost battery and pendals for complete installation.
① Open the quick release, adjust the handlebar direction
upward to loose the wire.
③ Adjust the handlebar direction, to make it at an angle of 15°-20° with the horizontal line, then close the quick release,
to complete the unfolding stem.
② Lift the stem from bottom to top, open the stem
clamp, adjust the handlebar and close the stem clamp.
15°-20°
Caution: Please operate by the instruction, otherwise
may cause wire breaking
7
