8/Product Connection
Table(8.1-1)
Accessories
User manual
Warranty card
Female plug
Signal cable
Safety wire
Fuse
QTY
1
1
1
1
1
2
UNIT
PCS
PCS
PCS
PCS
PCS
PCS
10A 6X30
Power
100-240V~
Fuse
8.1 Included items
FINE 4019 PIXIE PLUS LED is packed with flight case.One single standard flight
case carries two fixtures, Included items listed below (shown as table 8.1-1):
8.2 Power Connection
Power supply and fuses’ type and rating:
Notice: Type Y attachment for power supply connection. Method of attachment of the
cable or cord such that any replacement can only be made by the manufacturer, his
service agent or similarly qualified person.
The person must have the relevant qualification to connect the power supply. The AC
power voltage shall be suitable to the lamp provided with over-loading or creepage
protection.
1. Connecting the equipment to the power supply, do not connect to silicon box
system, or else, it will destroy the equipment.
The fixture is provided with standard 3-pin socket. Please according to table 8.2-2
connect to power supply, Yellow/green line must be earthed. If you still have any
question to the installation, please consultant with the experienced electrician.
2. When power is supplied, put the base switch to the position “I”.
Color
Brown
Blue
Yellow/Green
Wire
Live
Neutral
Earth
Mark
L
N
8.3 Signal Connection
Data linkage for the fixture may be provided by DMX512 connection and wireless
linkage.
Table(8.2-2)
Table(8.2-1)
