5.3 Fuse(s) Test And Replacement
5.3.1 Fuse(s) Test
To test the internal fuses of this Meter:
1. Set the rotary switch to “ ” position.
2. Turn this Meter on.
3. To test F2 (15A, 600v), plug a test lead into the VΩ input terminal
and touch the probe to the A input terminal.
The display should read about 0.000V. If the display reads
i
. . .
(overload), replace the fuse and test again. If the display reads any
other value, have this Meter serviced.
4 To test F1 (2A, 600V), move the probe from the A input terminal to
the mAµA input terminal.
The display should read 0.5V~0.6V. If the display reads
i
. . .
(overload), replace the fuse and test again. If the display reads any
other value, have this Meter serviced.
5.3.2 Fuse(s) Replacement
1. Unplug the test leads. Remove the rubber boot from the instrument.
2. Remove the screws in the rear of the instrument and separate the
front and rear housing.
3. Replace the fuses(s) with the same type and size as the one
removed.
4. Snap the f
r
ont and rear housing back together and reinstall the
screws.
5. Reattach the rubber boot.
NOTE: When servicing the Meter, use only the replaceable parts
specified.
BT1 Battery, 9 Volt
F1 Fuse 2A, 600V RMS
F2 Fuse 15A, 600V RMS
TL1 Test Lead Set
C2Y Rubber Boot (Yellow)
6. ACCESSORIES
