DO NOT OPERATE THIS FIREPLACE WITHOUT THE
GLASS DOOR OR WITH A BROKEN GLASS DOOR.
Installing the Glass Beads and
Optional River Rocks
Beads
The C-View-PRC Series are supplied with Designer Glass beads.
Remove the Door and trim as shown in the previous Instruction. Fol-
low these instructions to ensure all parts are removed or replaced as
required.
Once the Trim and glass door are removed place the marbles ran-
domly across the pan surrounding the burners as shown in Figure 18.
NOTE: DO NOT Cover burners with beads or the optional rocks as
shown in Figure 18.
Optional River Rocks
The C-View-PRC Series has the option of installing the optional
cultured rocks which mimic real stone. They are attrative yet designed
to withstand a high temperature environment such as inside a gas fire-
place. These may be spaced at random, or in a visual pattern of your
preference. See the Montigo web site for photographs and ideas.
www.montigo.com
Note: Ensure the rocks or beads do not cover the Burners.
Figure 18. Installation of glass beads .
installing the doors:
Install the doors in reverse order as shown in Steps 1 through 4.
Important: when re-installing screws into their original location, ALWAYS
hand tighten with screwdriver to ensure proper tension on all screws.
CAUTION!
DO NOT OVERTIGHTEN with an electric appliance (Screw-
driver). Most electric drills, or turning device's have torque set-
tings, and if this setting is set too high it will strip the threads in
the inserts. See the procedure above for re-installing the door.
WARNING!
Do not attempt to clean glass when hot.
Do not clean glass with abrasive materials as any glass etch-
ing may cause premature glass failure.
CAUTION!
Fireplace gas control must be in the “OFF” position and pilot
and main burners extinguished when cleaning appliance with
a vacuum.
Doors can get very hot. Handle only when cool.
Maintenance
CAUTION!
Page 13
