LCD-80F Annunciator SW1 DIP Switch Settings
12
Document 51338 Rev. B 08/24/05 P/N 51338:B
4 through 6 = Configuration for use with a particular FACP.
Switches 4, 5 and 6 are used to select the FACP (Fire Alarm Control
Panel) which is being connected to the LCD-80F. Refer to the
following table for the appropriate switch settings.
Programming Note: Depending on the FACP which is connected to
the LCD-80F, it may be necessary to enable communication with the
annunciator in the FACP programming. Refer to the appropriate
FACP manual for programming information.
7 and 8 = Future use.
Fire Alarm Control Panel SW1-4 SW1-5 SW1-6
Use This Setting OFF OFF OFF
Future Use OFF OFF ON
Future Use OFF ON OFF
Future Use OFF ON ON
Future Use ON ON OFF
Future Use ON OFF ON
Future Use ON ON OFF
Future Use ON ON ON
