FireBird Combi Range - Page 39

38
Kitchen
Radiator 1
Radiator 2
Radiator 3
Radiator 4
Radiator 5
Radiator 6
Bathroom
Cold Water &
Storage Tank
Feed &
Expansion
Tank
Service Main
Conventional
Boiler
Motorized
Val ve
Pump
Copper
Cylinder
Kitchen
Radiator 1
Radiator 2
Radiator 3
Radiator 4
Radiator 5
Radiator 6
Bathroom
Service Main
Firebird
Combi
Boiler
Domestic Cold Feed
Domestic Hot
Central Heating Cold
Central Heating Hot
Domestic Cold Feed
Domestic Hot
Central Heating Cold
Central Heating Hot
Firebird Combi System
Typical Conventional
Boiler System
