45
10-E Combi Parts Description
10
SPARE PARTS-BOILER
ITEM COMPONENT PART No. Qty
No. per boiler
18 Combi Boiler 50/70 - 70/90 FC 0310690 1
Combi Boiler 90/120 FC 0310612 1
19 Combi Tank 50/70 - 70/90 FC 0310790 1
Combi Tank 90/120 FC 0310712 1
20 Combustion chamber door 50/70 - 70/90 FC 0310890 1
Combustion chamber door 90/120 FC 0310812 1
20a Door Gasket 50/70 - 70/90 FC 03109 1
Door Gasket 90/120 FC 0310912 1
21 Viewing glass bracket FC 03110 1
21a Viewing glass FC 03111 1
21b Viewing glass gasket P70-L-45 1
22 Flue gas analysis point blank FC 03113 1
22a Flue gas analysis point gasket FC 03114 1
23 Flue adapter FC 03115 1
23a Flue adapter gasket FC 03116 1
23b M8 x 140mm Bolt FC 03117 1
24 50/70 - 70/90 Baffle P90-L-09 3-4
24b 90/120 Baffle P120-L-09 8
25L Left side panel FC 03118L 1
25R Right side panel FC 03119R 1
26 Front panel 50/70 - 70/90 FC 03120 1
Front panel 90/120 FC 0312012 1
27 Top panel 50/70 - 70/90 FC 03121 1
Top panel 90/120 FC 0312112 1
27a Top panel blanking plate FC 03122 1
27b Top panel flue finishing plate FC 03123 1
28 Drip tray FC 03124 1
29 Foil Lagging FC 03125 1
30 RDB Burner See page 41 1
30a Burner flange 1
30b Burner flange gasket 1
31 Flexible air hose FC 03126 1
32 Control panel back FC 03129 1
32a Control panel front 50/70 - 70/90 FC 03130 1
Control panel front 90/120 FC 0313012 1
32b Control panel top FC 03131 1
To Next Page
