PLUME KIT
80 mm 45˚ bend
Wall bracket
Extensions
X=250 / 500 / 1000 / 1250 [mm]
80 mm 90˚ bend
CONDENSING BOILER CHIMNEY INSTALLATION
System 35 flexible liner
suitable for condensing
applications
System 35
adaptor
45˚ bend
500mm
adjustable length
45˚ bend
500mm
length
Boiler adaptor
System 35
clamp plate
Condensing
birdguard
Condensing
birdguard
System 35
clamp plate
System 35 flexible liner
suitable for condensing
applications
System 35
adaptor
500mm
Adjustable length
Boiler adaptor
Condensing
boiler
Condensing
boiler
Boiler
C12-18
C20
C26
C35
C44
C58
C73
C100
Diameter
100mm
125mm
125mm
125mm
150mm
150mm
150mm
180mm
FLUE SIZE
NOTE:
All brick chimney constructions must comply with current building
regulations and BS 5410 Part 1: 2014. Insulated factory made
chimneys should comply with BS 4543.
Single wall stainless flue
suitable for condensing
boilers. Available in
stainless steel finish or
white finish
HEATPAC FLUE
45˚ terminal should be tilted up
to prevent condensate droping
from end of flue
For right hand flue option, remove the
two screws securing the flue, rotate the flue
and swap the removable side panels
